Echo CS-3400

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR - WT-402A112300139132
COVER, METERING DIAPHRAGM1123142039301
NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------2
SHAFT, THROTTLE1123117396303
SPRING, THROTTLE RETURN1123113475304
SCREW, THROTTLE VALVE2123114039305
VALVE, THROTTLE1123116052306
CLIP, THROTTLE SHAFT1123127150307
LEVER, THROTTLE1123150392308
SCREW, THROTTLE LEVER2123114039309
NEEDLE, HIGH SPEED11231203923010
NEEDLE, LO SPEED11231183923011
CAP, MIXTURE LIMITER21231513923012
SCREW, IDLE ADJUST11231341973013
SPRING, IDLE ADJUST11231331113014
COVER, FUEL PUMP11231240932015
SCREW, FUEL PUMP COVER11231100393016
INCLUDES ITEMS 18-29REPAIR KIT11231003913017
SCREW, METERING DIAPHRAGM
COVER
4------------------18
DIAPHRAGM, METERING1------------------19
GASKET, METERING DIAPHRAGM1------------------20
SCREW, METERING LEVER PIN1------------------21
PIN, METERING LEVER1------------------22
LEVER, METERING1------------------23
VALVE, INLET NEEDLE1------------------24
SPRING, METERING LEVER1------------------25
PLUG, WELCH1------------------26
SCREEN, INLET1------------------27
DIAPHRAGM, FUEL PUMP1------------------28
GASKET, FUEL PUMP1------------------29
INCLUDES ITEMS 31-34DIAPHRAGM/GASKET KIT11231010596030
DIAPHRAGM, METERING1------------------31
GASKET, METERING DIAPHRAGM1------------------32
DIAPHRAGM, FUEL PUMP1------------------33
GASKET, FUEL PUMP1------------------34
99922203114_3400/T1 - 11 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Carburetor -- WT-402A S/N: 01844_Up
