Echo CS-3400 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-8REAR HANDLE SET1351100391311
SCREW, 4X102900238040102
SCREW, 4X163900256040163
CONTROL,THROTTLE1178010391304
SPRING, THROTTLE RETURN1178043391315
PIN, SPRING 4X251900345400256
LOCKOUT,THROTTLE1178090391307
PIN, SPRING 4X201900345400208
SCREW, 5X351900238050359
SCREW, 5X1419002380501410
CAP, CUSHION21009181513011
CUSHION21009213913012
GROMMET,THROTTLE11782103913013
ROD,THROTTLE11780113913114
NUT, FLANGE 519005160000515
SCREW11009153393016
CUSHION11009103563017
SCREW, 4X1649002560401618
HANDLE, FRONT13516103913019
SCREW, 4X1449002530401420
CUSHION11009073913021
SUPPORTER13511233913122
INCLUDES ITEMS 24-26HARNESS RING KIT1P02100028023
SCREW, 4X1629002380401624
FIXTURE, HARNESS13003143913025
RING, HARNESS13010165273026
99922203114_3400/T1 - 13 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Handles,Throttle Control

Echo CS-3400 Specifications

General

Bar Length	16 inches
Power Output	1.6 kW
Engine Displacement	34.0 cc
Weight	4.0 kg
Chain Pitch	3/8 inch
Chain Gauge	0.050 inches
