Echo CS-3400 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEM 2CLUTCH ASY1P0210002601
PLATE, CLUTCH1175019394302
DRUM, CLUTCH1175005391313
BEARING, NEEDLE1175012356304
WASHER, CLUTCH1175014391305
CHAIN, SAW 91VG-45E - 12"19170456
CHAIN, SAW 91VG-52E - 14"19170526
CHAIN, SAW 91VG-57E - 16"19170576
BAR, GUIDE - 12" DOUBLE GUARD11203745017
BAR, GUIDE - 14" DOUBLE GUARD11403752017
BAR, GUIDE - 16" DOUBLE GUARD11603757017
BOLT1433016391318
TENSIONER1433014039319
GUARD, KICK KIT1289490110
UNKNOWN------------------11
99922203114_3400/T1 - 21 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Clutch Assembly, Bar & Chain,Tools

Echo CS-3400 Specifications

General

Bar Length	16 inches
Power Output	1.6 kW
Engine Displacement	34.0 cc
Weight	4.0 kg
Chain Pitch	3/8 inch
Chain Gauge	0.050 inches
