Echo CS-3400 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
MAY ONLY BE USED WITH 15662639130 - COIL,
IGNITION
FLYWHEEL1156800356301
MAY ONLY BE USED WITH 15680035630 - FLYWHEELCOIL,IGNITION1156626391302
SCREW, 5X202900238050203
NOT REQUIRED1------------------4
LEAD1162010391315
SWITCH,IGNITION1163400198306
WASHER 81900600000087
NUT 81900500000088
SPRING, RETURN2177234354309
PAWL, STARTER21772183563110
SPACER, RATCHET21772470463011
WASHER 529006030000512
SCREW, 5X1229002160501213
SPACER21501171643014
CAP, SPARK PLUG11590120162015
COIL, SPARK PLUG CAP11590110343216
PLUG, SPARK - BPM-7A11590101063017
PLUG, SPARK - BPMR-7A
1
11590101023017
GROMMET11561100492018
INCLUDES ITEMS 20-30STARTER ASY11772003963119
COVER, STARTER11772323953220
GUIDE, ROPE11772273913121
SCREW, 3X1419002960301422
GRIP, STARTER ROPE11772283543023
SPRING, REWIND11772203963024
PLATE, STARTER11772213963025
ROPE, STARTER - 3X850mm
2
11772260653026
DRUM, STARTER11772153563227
WASHER11772140463028
SCREW, 4X1449002530401429
PLATE, GUIDE11015343953030
SCREW, 4X1649002560401631
LABEL, ECHO18901184933032
Footnotes
1: CANADA MODELS
2: BULK OPTION: 99944440000
99922203114_3400/T1 - 5 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Ignition, Starter Assembly

Echo CS-3400 Specifications

General

Bar Length	16 inches
Power Output	1.6 kW
Engine Displacement	34.0 cc
Weight	4.0 kg
Chain Pitch	3/8 inch
Chain Gauge	0.050 inches
