Echo CS-3400 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-8MUFFLER ASY1145803355321
GASKET, MUFFLER1145510139312
MUFFLER1145858139313
SILENCER1145859139304
LID, MUFFLER1145861355305
SCREW, 4X84900250040086
GUIDE, EXHAUST1145876355307
SCREEN, MUFFLER1145862139318
PLATE, EYE1145642139309
BOLT, MUFFLER21010231393010
INCLUDES ITEMS 12-13CLEANER LID ASY11303023913311
INCLUDES ITEMS 13BOLT ASY11304061393212
E-RING 419007000000413
FILTER, AIR11303103913114
SCREW, 5X4529002380504515
PLATE, PREVENT11290113913016
ROD, CHOKE11785103923017
SHUTTER, CHOKE11785153913018
WASHER21785160393019
S/N 001001-011843CARBURETOR - WT-385A11230006013120
S/N 011844 & UPCARBURETOR - WT-402A11230013913220
GASKET, INTAKE1V10300002121
SCREW, 5X1829002500501822
INSULATOR KIT11300003913123
GASKET, INTAKE1V10300012024
SEAL11300123913025
99922203114_3400/T1 - 7 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Intake, Exhaust

Echo CS-3400 Specifications

General

Bar Length	16 inches
Power Output	1.6 kW
Engine Displacement	34.0 cc
Weight	4.0 kg
Chain Pitch	3/8 inch
Chain Gauge	0.050 inches
