Echo CS-3400 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR - WT-385A112300060131
COVER, METERING DIAPHRAGM1123142039301
NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------2
SHAFT, THROTTLE1123117396303
SPRING, THROTTLE RETURN1123113475304
SCREW, THROTTLE VALVE1123114039305
VALVE, THROTTLE1123116052306
CLIP, THROTTLE SHAFT1123127150307
LEVER, THROTTLE1123150392308
SCREW, THROTTLE LEVER1123150392309
NEEDLE, HIGH SPEED11231203953010
NEEDLE, LO SPEED11231182443011
SCREW, IDLE ADJUST11231341973012
SPRING, IDLE ADJUST11231331113013
COVER, FUEL PUMP11231240932014
SCREW, FUEL PUMP COVER11231100393015
INCLUDES ITEMS 17-29REPAIR KIT11231003733016
SCREW, METERING DIAPHRAGM
COVER
4------------------17
DIAPHRAGM, METERING1------------------18
GASKET, METERING DIAPHRAGM1------------------19
SCREW, METERING LEVER PIN1------------------20
PIN, METERING LEVER1------------------21
LEVER, METERING1------------------22
VALVE, INLET NEEDLE1------------------23
SPRING, METERING LEVER1------------------24
PLUG, WELCH1------------------25
SPRING, ADJUST NEEDLE2------------------26
SCREEN, INLET1------------------27
DIAPHRAGM, FUEL PUMP1------------------28
GASKET, FUEL PUMP1------------------29
INCLUDES ITEMS 31-34DIAPHRAGM/GASKET KIT11231010596030
DIAPHRAGM, METERING1------------------31
GASKET, METERING DIAPHRAGM1------------------32
DIAPHRAGM, FUEL PUMP1------------------33
GASKET, FUEL PUMP1------------------34
99922203114_3400/T1 - 9 - REVISED 10/04/06
Table of Contents Part Number Index
CS-3400 Type 1 CHAIN SAW Carburetor -- WT-385A S/N: 001001 - 011843

Echo CS-3400 Specifications

General

Bar Length	16 inches
Power Output	1.6 kW
Engine Displacement	34.0 cc
Weight	4.0 kg
Chain Pitch	3/8 inch
Chain Gauge	0.050 inches
