17
ES-210, 211
ITEM PART NUMBER QTY DESCRIPTION REMARKS
SERIAL NUMBERS: 02001001-02999999
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
20012420661 1 GRID, FAN CASE
13040620660 1 KNOB, FASTENER
90060300005 1 WASHER 5
90025305014 1 SCREW 5X14
20015005060 1 SHAFT, GRID
20015205060 1 SPRING, GRID
20010920662 1 FAN CASE ASY - LEFT INCLUDES ITEM 8
22012020561 1 CUSHION
90025305020 6 SCREW 5X20
90025604022 2 SCREW 4X22
16381020660 1 BRACKET, SHUT OFF SWITCH
16333520560 1 LEVER, SHUT OFF ACTUATOR
16340020660 1 SWITCH, SHUT OFF
X503001320 1 LABEL, MODEL -- ES-211
89016008761 1 LABEL, CAUTION
90050000008 1 NUT 8
20018008761 1 CUTTER, SHREDDER
20001006363 1 FAN
10013205660 1 WASHER
20001105661 1 HUB, FAN
16340120560 1 SWITCH, STOP
90023805025 1 SCREW 5X25
17805420560 1 CONTROL, THROTTLE
90060300005 1 WASHER 5
90051600005 1 FLANGE NUT 5
90050200005 1 NUT 5
35133520560 2 CUSHION
90016204022 4 BOLT 4X22
89022808760 1 LABEL, CAUTION
89016003360 1 LABEL, CAUTION
13201056330 1 PIPE, RETURN - 3X6X90mm BULK OPTION: 90017
A356000030 1 VENT ASY
13132840630 1 COVER, VENT
13131239130 1 PIPE, VENT - 3X5X70mm
BULK OPTION: 90014
43721011131 1 PIPE, FUEL - 3X5X90mm BULK OPTION: 90014
13211546730 1 GROMMET, FUEL
13201103360 1 CONNECTOR, FUEL PIPE
13201212360 1 PIPE, FUEL
13120507320 1 STRAINER, FUEL
13100520560 1 TANK, FUEL
13104528230 2 SPACER
90060300005 2 WASHER 5
90023805016 2 SCREW 5X16
13100455530 1 FUEL TANK CAP ASY INCLUDES ITEM 45-46
13101655830 1 GASKET, FUEL CAP
13105156030 1 CONNECTOR, FUEL CAP
17801020560 1 CONTROL, THROTTLE
17801120560 1 ROD, THROTTLE
90025305020 5 SCREW 5X20
89016006361 1 LABEL, HOT
SERIAL NUMBERS: 02001001-02006932
20010820662 1 FAN CASE ASY - RIGHT INCLUDES ITEM 52
22012020661 1 CUSHION
A190000030 1 COVER, ENGINE
SERIAL NUMBERS: 02006933-02999999
P021003701 1 FAN CASE ASY - RIGHT INCLUDES ITEM 55
22012020661 1 CUSHION
A190000030 1 COVER, ENGINE
ES-211
FAN CASE, ENGINE COVER, FUEL SYSTEM
