REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEM 2-17SHORT BLOCK1SB10741
SCREW 5X222900162050222
CYLINDER1A1300005503
GASKET, CYLINDER
1
1V1000001604
INCLUDES ITEMS 6-10PISTON KIT1P0210077725
RING, PISTON1A1010000906
PIN, PISTON1100013115207
CIRCLIP, PISTON PIN2100015046308
SPACER, PISTON PIN2100014089609
BEARING, NEEDLE11001130593010
CRANKSHAFT ASY1A01100031211
INCLUDES ITEMS 13-17CRANKCASE KIT11002040536112
OIL SEAL21002124203113
DOWEL PIN - 4X7.8mm2V62200002014
GASKET, CRANKCASE
1
11002424203015
BEARING, BALL - 62012940353620116
SCREW 5X2839001620502817
GASKET KIT1P02101229018
COIL, IGNITION1A41100013019
SCREW 4X2029001620402020
TUBE, INSULATOR1V47500220021
BUSHING11561100492022
CAP, SPARK PLUG11590120162023
TERMINAL, SPARK PLUG CAP11590110343224
SPARK PLUG -- BPM-8Y11590101983025
CANADA MODELSSPARK PLUG -- BPMR-8Y1A42500000026
LEAD, IGNITION11620215283027
GROMMET11561140492028
FLYWHEEL1A40900015029
WASHER, CLUTCH11750140536030
PLATE, CLUTCH11750190492031
INCLUDES ITEMS 33-35CLUTCH ASY11750000656032
SPRING, CLUTCH21750180596033
SHOE, CLUTCH21750090513134
HUB, CLUTCH11750160492035
COVER, ENGINE - GRAY1A16000015136
SCREW 4X2029001620402037
SCREW 4X81911070400838
LABEL - CAUTION -- HOT18901600636139
Footnotes
1: Also Included In GASKET KIT
99922203278_150/10 - 15 - REVISED 04/30/09
Table of Contents Part Number Index
HC-150 Hedge Trimmer Engine, Short Block, Ignition, Clutch, Cylinder Cover
