REMARKSDESCRIPTIONQTYPART NUMBERITEM
DRUM, CLUTCH1175005065601
CIRCLIP 351900702000352
BEARING, BALL1900872362023
BEARING, BALL1900870362024
CIRCLIP 141900701000145
CUSHION, FUEL TANK1131920618306
CASE, GEAR1C5310000517
SCREW 4X162900163040168
NIPPLE, GREASE1880110542309
NUT 629005000000610
NUT64330220646011
WASHER46991180456012
BLUNT16991250306013
SUPPORT, BLADE1X42500001014
SCREW 5X3019002120503015
SCREW 6X3029002120603016
WASHER66991180456017
BOLT 656991150466018
BOLT, BLADE16991150656019
SCREW 4X1269001620401220
LID, GEAR CASE16104110656021
GASKET, GEAR HOUSING
1
16104140656022
SEAL16104260656023
GEAR, SPUR2V65000025024
BLADE2X41100002025
WASHER16890250536026
WASHER16890250656027
COVER, BLADE1X49500001028
WRENCH, W/SCREWDRIVER18954100696029
GASKET KIT1P02100161030
GASKET KIT1P02100471031
Footnotes
1: Also Included In GASKET KIT for SERIAL NUMBERS: 02001001-07999999 ONLY
99922203278_150/10 - 17 - REVISED 04/30/09
Table of Contents Part Number Index
HC-150 Hedge Trimmer Cutters, Gear Case,Tools
