Echo HC-1500 - Specifications; Technical Specifications

17
Mass :
Unit with specified cutting blade, empty tank kg 4.7 5.7
Unit with specified cutting blade, full tank kg 4.9 6.1
Volume :
Fuel tank L 0.30 0.50
Cutting device :
Type Dual action, double sided
Length mm 580 725
Pitch mm 35
Height mm 21
Gear ratio and lubrication : 5.9 reduction and good quality lithium grease
External Dimensions :
length × width × height mm 960 × 235 × 200 1,135 × 240 × 215
Engine :
Type Air cooled Two stroke single cylinder
Engine displacement mL (cm³) 21.2
Maximum shaft brake power
(Referred to ISO 8893) kW 0.56 0.6
Engine speed at maximum power r/min 6,500 6,500
Recommended maximum engine speed r/min 10,000
Recommended engine idling speed r/min 3,000
Engine speed at beginning of clutch engagement r/min 3,800 3,700
Carburettor Diaphragm type
Ignition Flywheel magneto - CDI system
Spark plug CHAMPION RCJ-8Y CHAMPION RCJ-7Y
Starter Recoil starter
Clutch Automatic Centrifugal
Fuel : Regular grade petrol. Minimum 89 Octane
unleaded petrol is recommended. Do not use fuel
containing methyl alcohol or more than 10 % of
ethyl alcohol.
Oil Two stroke, air-cooled engine oil. 50 : 1 for ISO-L-
EGD Standard (ISO/CD 13738), JASO FC grade
and ECHO Premium 50 : 1 oil.
Ratio 50 : 1 (2 %)
Fuel consumption at engine maximum power L / h 0.56 0.6
Specific fuel consumption at engine maximum
power g/(kW•h) 740
Sound Pressure Level :
(Referred to EN 27917) LpAav = dB(A) 95 94
Guaranteed Sound Power Level :
(2000/14/EC) LWA = dB(A) 110 109
Vibration levels : (Referred to ISO 7916)
Idling m/s² 10.2 3.6
Racing m/s² 15.0 6.1
SPECIFICATIONS
HC-1500 HC-1600
