Echo PB-200

WARNING DANGER
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator’s Manual, which must be read and understood for proper and safe operation.
Power Blower
Operator's Manual
MODEL PB-200
X753003040
01/07
X7531135800

Echo PB-200 Specifications

General

Engine Displacement	21.2 cc
Type	Handheld
Power Source	Gasoline
Engine Type	2-stroke
Fuel Tank Capacity	13.5 fl oz

Summary

INTRODUCTION

THE OPERATORS MANUAL

Instructions to read and understand the manual for future reference.

SAFETY

MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION

Explains safety alerts, symbols, and keywords used in the manual.

INTERNATIONAL SYMBOLS

Lists and explains international symbols used on the product and in the manual.

PERSONAL CONDITION AND SAFETY EQUIPMENT

Discusses the importance of operator's physical condition and required safety gear.

OPERATOR SAFETY GUIDELINES

Physical Condition and Personal Protective Equipment

Advises operating only when physically well and wearing proper PPE like eye and hand protection.

Proper Clothing and Environmental Precautions

Details recommended clothing, and precautions for hot weather and vibration.

OPERATOR SAFETY GUIDELINES

Repetitive Stress Injury Prevention

Explains RSI/CTS risks and methods to reduce them, including breaks and posture.

Work Area and Stance Safety

Advises clearing the area, maintaining a firm grip, solid stance, and avoiding hot surfaces.

EQUIPMENT CHECK

Pre-Operation Checks and Approved Attachments

Covers checking for loose parts, leaks, using approved attachments, and professional repairs.

EMISSION CONTROL

EPA Phase 2 Compliance

Describes the emission control system and compliance period.

PRODUCT DESCRIPTION AND DECALS

Safety Decals and Labels

Instructs to locate, ensure legibility, and follow instructions on safety decals and labels.

COMPONENT IDENTIFICATION

Key Operating Controls

Identifies and describes the stop switch, throttle trigger, choke, and purge bulb.

Engine and Fuel System Components

Describes the spark plug, muffler, air cleaner, fuel tank cap, and blower pipes.

Starter and Throttle Mechanisms

Details the recoil starter handle and throttle position lever.

ASSEMBLY AND OPERATION

Installing Blower Pipes

Step-by-step instructions for attaching the blower pipes and nozzle.

Fuel Requirements and Handling

Specifies approved gasoline types and maximum ethanol content allowed.

FUEL HANDLING AND MIXING

Two Stroke Oil and Fuel Handling Safety

Details required oil, and provides crucial safety warnings for handling fuel.

Fuel Mixing Instructions

Step-by-step guide for mixing fuel and oil at a 50:1 ratio.

STARTING COLD ENGINE

Cold Start Procedure Steps

Guides through stop switch, throttle, choke, purge bulb, and recoil starter steps.

STARTING WARM ENGINE

Warm Start Procedure Steps

Outlines the process for starting a warm engine, omitting the choke.

STOPPING ENGINE

Engine Stop Procedure

Instructions on returning the engine to idle and using the stop switch.

OPERATING THE BLOWER

Operating Procedures and Speed Control

Covers warming up, speed control using triggers/levers, and task-appropriate speeds.

MAINTENANCE OVERVIEW

Skill Levels and Maintenance Intervals

Defines skill levels for tasks and provides a table of maintenance intervals.

MAINTENANCE PROCEDURES

Air Filter Maintenance

Instructions for cleaning or replacing the air filter.

Fuel Filter Maintenance

Steps for checking and replacing the fuel filter.

MAINTENANCE PROCEDURES

Spark Plug Maintenance

Details inspection, cleaning, replacement, and gapping of the spark plug.

Cooling System Cleaning

Explains the importance of cooling and how to clean the intake grill.

MAINTENANCE PROCEDURES

Cleaning Cylinder Fins

Step-by-step guide to cleaning the engine's cylinder fins.

EXHAUST SYSTEM MAINTENANCE

Spark Arrestor Screen Cleaning

Instructions for checking and cleaning the spark arrestor screen in the muffler.

MAINTENANCE PROCEDURES

Cylinder Exhaust Port Cleaning

Advises inspection and cleaning of the cylinder exhaust port.

CARBURETOR ADJUSTMENT

Engine Break-In and Idle Speed Adjustment

Explains break-in period and how to adjust idle speed using a tachometer.

TROUBLESHOOTING

Troubleshooting Chart

A chart listing common problems, their causes, and remedies.

STORAGE PROCEDURES

Long Term Storage Preparation

Provides instructions for preparing the unit for storage exceeding 30 days.

SPECIFICATIONS

General & Engine Specifications

Model, dimensions, weight, engine type, displacement, bore, stroke, carburetor.

Ignition, Exhaust & Fuel Specs

Ignition system, exhaust system, fuel type, oil type, and fuel/oil ratio.

Operating Performance Specs

Fuel tank capacity, recoil starter, WOT speed, idle speed, air volume, air speed.

Noise & Compliance

Sound level rating and safety compliance information.

SERVICING INFORMATION

Parts, Serial Number & Service

Explains obtaining parts, serial numbers, and warranty service requirements.

Product Support & Manuals

Provides contact for support and guides on obtaining manuals and registration.
