ITEM PART NUMBER QTY DESCRIPTION REMARKS
PB-200, 201
SERIAL NUMBERS: 02001001-02999999
PB-201
CARBURETOR -- C1U-K62
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
A021000180 1 CARBURETOR — C1U-K62
12534452130 2 SCREW, METERING DIAPHRAGM COVER
12534213210 1 COVER, METERING DIAPHRAGM
------------------ 1 BODY, CARBURETOR
P005000500 1 NOZZLE, CHECK VALVE NOT AVAILABLE SEPARATELY
12532908560 1 CAP, MIXTURE LIMITER - HIGH SPEED
P005000400 1 NEEDLE - HIGH SPEED
P005000490 1 SHAFT, THROTTLE
12531308560 1 SPRING, THROTTLE RETURN
12531413930 1 SCREW, THROTTLE VALVE
12531649030 1 VALVE, THROTTLE
12532713930 1 CLIP, THROTTLE SHAFT
12535020560 1 LEVER, THROTTLE
12534813930 1 SCREW, THROTTLE LEVER
12533406860 1 SCREW, IDLE ADJUST
12537813930 1 PIECE, FRICTION
12538313310 1 BASE, PURGE
12538108660 1 PUMP, PURGE
12536311610 1 RETAINER, PURGE PUMP
12531011610 2 SCREW, PURGE BASE
12533942030 1 SCREW, METERING LEVER PIN
P005000580 1 REPAIR KIT INCLUDES ITEMS 22-31
------------------ 1 DIAPHRAGM, METERING
------------------ 1 GASKET, METERING DIAPHRAGM
------------------ 1 PIN, METERING ARM
------------------ 1 LEVER, METERING
------------------ 1 VALVE, INLET NEEDLE
------------------ 1 SPRING, METERING LEVER
------------------ 1 WELCH PLUG
------------------ 1 STRAINER
------------------ 1 DIAPHRAGM, FUEL PUMP
------------------ 1 GASKET, FUEL PUMP
12530313310 1 DIAPHRAGM/GASKET KIT INCLUDES ITEMS33-36
------------------ 1 DIAPHRAGM, METERING
------------------ 1 GASKET, METERING DIAPHRAGM
------------------ 1 DIAPHRAGM, FUEL PUMP
------------------ 1 GASKET, FUEL PUMP
