Echo SHR-4100

14
MAINTENANCE AND CARE
CLEANING AIR FILTER
NOTE
Clean air filter after each use.
• Close choke and loosen screws.
• Remove air cleaner cover, grid and air filter.
• Then check and/or clean air filters by washing
in a suitable solvent when heavily soiled.
• Dry filter before reinstalling.
Filter
Fuel tank cap
REPLACING FUEL FILTER
NOTE
A clogged fuel filter will cause hard starting or
poor engine performance.
• Pick up the fuel filter through fuel tank
opening with a piece of steel wire or the like.
• Remove old filter from fuel line.
• Install new fuel filter.
CAUTION
Keep fuel tank clean - do not allow dirt or
debris to enter fuel tank.
NOTE
Make sure fuel filter goes to bottom of the tank
when installing.
Grid
Air cleaner cover
Fuel filter
