11
Sh r e d 'N'Va c
®
O
p e r a t O r 'S Ma N u a l
Install Bag
1. Stand unit upright on blower base.
2. Release locking ring (C) with a coin or screwdriver, and rotate so
that lock symbol (A) is at top of ring.
3. Align locking ribs (L) on elbow with recesses (D) in locking ring,
and slide elbow into locking ring.
4. After inserting elbow into fan case so that line (M) meets locking
ring (C), rotate locking ring clockwise 1/8 turn to lock elbow in
place.
5. Place debris bag opening over ared end of elbow, and cinch bag
(O) securely at the position (N) with Velcro strap.
