Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

13
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
89016054130 1 LABEL, CAUTION
35130109230 1 HANDLE BRACKET ASY INCLUDES ITEMS 3-4
90014205025 4 BOLT 5X25
90014206030 2 BOLT 6X30
35121023430 1 HANDLE, FRONT - LEFT
35101005530 1 HANDLE, FRONT - RIGHT
35131102330 1 GRIP, HANDLE - LEFT
35131522130 1 GRIP, HANDLE - RIGHT
17802441830 1 BRACKET, THROTTLE
90022005025 1 SCREW 5X25
17811005330 1 SCREW
90056000005 1 LOCKNUT 5
90050000005 1 NUT 5
16340149230 1 SWITCH, IGNITION
17801006460 1 CONTROL, THROTTLE
17804305230 1 SPRING, THROTTLE RETURN
17800141330 1 CABLE, THROTTLE
17810605330 1 BAND
90022005010 1 SCREW 5X10
17811104930 1 CLIP, THROTTLE WIRE
17812708030 1 TUBE 10X11X750
17802105530 2 LOCKNUT
30120521330 1 RING ASY
61060944730 1 DRIVESHAFT HOUSING ASY INCLUDES ITEMS 25-26
61024644730 2 FIXTURE, LINER
61021744730 1 LINER, FLEXIBLE
61001344730 1 SHAFT, FLEXIBLE
89015204930 1 LABEL, ALIGNMENT
30100052131 1 HARNESS ASY
30110541830 1 PAD, WAIST
SRM-2110 TYPE 1E
DRIVE SHAFT, HANDLES, THROTTLE, STOP SWITCH, HARNESS

Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 Specifications

General

Category	Brush Cutter
Model	SRM-2100
Displacement	21.2 cc
Type	TYPE 1E
Fuel Mix Ratio	50:1
Engine Type	2-Stroke
