12
Grass/Weed Blades Require:
Install Blade Conversion Kit, Includes metal shield
(A), barrier bar (B), and shoulder harness (C).
B
A
C
NOTE
The Barrier Bar is used to restrict rearward movement
of the unit. The Barrier Bar is NOT A HANDLE and
should not be gripped when using or carrying the unit.
Brush/Clearing Blades Require:
Install U-Handle / Blade Conversion Kit, Includes
metal shield (A), shoulder harness with hip pad
(C), and U-Handles (D).
A
C
D
Choosing the Correct Blade
WARNING
The type of Blade used MUST be matched to the type and size of material cut. An improper or dull blade can cause
serious personal injury. Blades MUST be sharp. Dull blades increase the chance of kick out and injury to yourself
and bystanders.

Echo SRM-225 - 12-08 Specifications

General

Engine Displacement	21.2 cc
Cutting Swath	17 inches
Engine Type	2-stroke
Starting System	i-30™ starting system
Shaft Type	Straight
Weight	10.1 lbs
Shaft Length	59 in
Warranty	2 year commercial
