REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- RB-K661A021000380
ROTOR COVER ASY1P0050006901
NUT, CABLE1P0050001202
SCREW, ROTOR COVER ASY3125344139313
SCREW, CABLE ADJUST1P0050007004
SWIVEL1P0050001805
E-RING1P0050001906
SCREW, THROTTLE ADJUST1P0050001007
O-RING1P0050002808
BODY, CARBURETOR
1
1------------------9
PLUG KIT1P00500037010
JET1P00500057011
PURGE BASE ASY1P00500053012
SCREW, PURGE BASE ASY1P00500027013
BULB, PURGE11253810866014
RETAINER, PURGE BULB1P00500025015
SCREW, PURGE BULB RETAINER41253106183016
COVER, DIAPHRAGM11253425213017
SCREW, DIAPHRAGM COVER21253445213018
SCREW, METERING LEVER PIN11253394203019
INCLUDES ITEMS 21-30REPAIR KIT1P00500056020
ROLLER, GUIDE1P00500029021
PIN, METERING LEVER1------------------22
VALVE, INLET NEEDLE1------------------23
LEVER, METERING1------------------24
SPRING, METERING LEVER1------------------25
STRAINER1------------------26
DIAPHRAGM, PUMP1------------------27
GASKET, PUMP1------------------28
GASKET, METERING1------------------29
DIAPHRAGM, METERING1------------------30
INCLUDES ITEMS 32-35DIAPHRAGM/GASKET KIT1P00500055031
DIAPHRAGM, PUMP1------------------32
GASKET, PUMP1------------------33
GASKET, METERING1------------------34
DIAPHRAGM, METERING1------------------35
Footnotes
1: NOT AVAILABLE SEPARATELY
99922203528_230/05 - 15 - REVISED 05/19/09
Table of Contents Part Number Index
SRM-230 Trimmer Carburetor -- RB-K66 S/N: 05001001 - 05004893
