Page #21 background imageLoading...
Page #21 background image
REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-18SHORT BLOCK1SB10611
SCREW 5X224900162050222
CYLINDER1A1300003413
GASKET, CYLINDER
1
1V1000000604
INCLUDES ITEMS 6-9PISTON KIT1P0210011025
RING, PISTON2A1010000006
PIN, PISTON1100013115207
CIRCLIP, PISTON PIN2100015046308
SPACER, PISTON PIN2100014115209
INCLUDES ITEM 11CRANKSHAFT ASY1A01100004210
BEARING, NEEDLE1V55300001011
INCLUDES ITEMS 13-18CRANKCASE KIT1P02100094112
OIL SEAL11002130553013
BEARING, BALL 600129008003600114
CIRCLIP 2819007020002815
GASKET, CRANKCASE
1
11002425593016
OIL SEAL11002122823017
SCREW 5X2549001620502518
Footnotes
1: Also Included In GASKET KIT
99922203528_230/06 - 21 - REVISED 05/19/09
Table of Contents Part Number Index
SRM-230 Trimmer Engine, Short Block -- SB1061

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo SRM-230 - PARTS CATALOG SERIAL NUMBERS 06001001-06999999 and is the answer not in the manual?

Echo SRM-230 - PARTS CATALOG SERIAL NUMBERS 06001001-06999999 Specifications

General IconGeneral
Engine Displacement21.2 cc
Shaft TypeStraight
ModelSRM-230
Serial Numbers06001001-06999999
Engine Type2-stroke
Starter SystemRecoil
Cutting Swath17 in. (43 cm)
Drive ShaftFlexible
