Echogear EGMF2 - Insert Concrete Anchors; Secure Wall Plate

13
09
08
Continue
STEP 2.5
on PAGE 14
CAUTION: DO NOT over-tighten
the lag bolts
07
. Tighten only enough to
securely fasten the wall plate
06
to the wall.
07
06
"whichever way your
mind works"
FLUSH
Use bottom
lag bolt
07
to level.
2X
Insert Concrete Anchors Secure Wall Plate
STEP 2B.3 STEP 2B.4
