ECI 1000-U LCD Installation Manual
Electronic Controls, Inc.
7073 North Atlantic Ave. Cape Canaveral, FL 32920
800-633-9788
www.eciamerica.com P a g e | 9
6.3 User Interface
6.3.1 Toggle switches
Run/Test – Two position switch. In RUN position the door board is controlled through the
controller interface. In the TEST position door operation is controlled through the
OPEN/CLOSE switch.
OPEN/CLOSE – 3 position switch. Middle position if off. With the RUN/TEST switch in the
TEST position door operation can be controlled with this switch.
NUDGE/LOCK – 3 position switch. Middle position if is off. With the RUN/TEST switch in
the TEST position both NUDGE and LOCK are controlled through this switch.
6.3.2 Keypad
+ button – Used to move curser up or increase speed settings
- button – Used to move curser down or decrease speed settings
ENTER - Used to select menu options or enter parameter settings
ESC – Used to exit menu or go to previous menu
6.3.3 LED Indicators
CL – On when CAM is on CL switch
DO17 - On when CAM in on CL switch
OL - On when CAM in on OL switch
OSDL - On when CAM in on OSDL switch
PL – On when CAM in on the PL switch
CLX – On when CAM in off the CLX switch
OLX – On when the CAM is off the OLX switch
SS – On when the CAM is on the SS switch
HDCSDL – On when cam is on switch
DO4 – On when DO4 present
DO7 – On when DO7 present
DO18 – On when DO18 present
6.3.4 Main Menu
Figure 1 - Main Menu
