BEFORE ASSEMBLY Firstly unpack and check all parts have been supplied. If you think
any parts are missing, first check the packaging again before calling the Eckman helpline
on 0844 441 3011
II. Specifications
Product Name: GRASSHOPPER(3-in-1 Mower/Aerator / Scarifier , With Optional
Roller) Model: EKETC6
Carton Size: 590x480x430mm
Product Size: 570x670x1190 mm
Net weight (with all accessory cassettes): 16.6 kgs
Gross weight: 19.7 kgs
The capacity of collection bag(fabric material) : 30.4 Litres
Working width of accessories 344mm (13 ½”)
Cutting height adjustment range:14-36mm
III. Assembly Instructions
Step 1 Attach the side bars to the handle bottom bars using the knobs, bolts and washers supplied
as illustrated in Figure 1..
Step 2 Attach the handle top with Foam Grip to the Side bars using the knobs, bolts and washers
as illustrated in Figure 1..
