V. Height Adjustments
1）Wheels height adjustments
The height of the machine above the ground can be adjusted by moving the height adjustment levers
to the required position. To set the lowest position, one at a time pull the adjustment levers located
next to the smaller wheels and move them to their highest position.To set the highest cutting position,
move the adjustment levers one at a time to their lowest position .
NOTE: The two height adjustment levers must be set to the same height positions.
2）Roller height adjustments
The Roller height can be adjusted by moving the height adjustment levers to the required position. This is
same as above wheels height adjustments. The only difference is roller height only has four height
grades,The function of the shorter screw is to prevent the user from setting the adjustment lever on the
fifth height grade or above. (see photos as below)
