Ecler APA2000 - Page 38

38
ECLER Laboratorio de electroacústica S.A.
Motors 166168, 08038 Barcelona, Spain
INTERNET http://www.ecler.es Email: info@ecler.es
50.0014.0200
OUT 1
PROBE
FAN
THERMAL
CONTROL
ANTICLIP CONTROL
CURRENT WILSON
CONVERTER LEVEL
MIRROR
CONVERTER LEVEL
DRIVER MOSFET N
OVERLOAD HIGH SIDE
DRIVER MOSFET N
FEEDBACK
ZOBEL
LOW SIDE OVERLOAD
CROWBAR DC PROTECT
OUTPUT SHUTDOWN SHUTDOWN OUTPUT
RELAY
PROTECTION AND TIMER
AC DETECT
++Vcc +Vcc
-Vcc
INPUT CIRCUIT
FAN CONTROL THERMAL PROTECT
THERMAL
MODULE
POWER MODUL CIRCUIT POWER MODUL CIRCUIT
OUT 2
CLIP/PROTECT
BUFFER
CH 2
CH 1
VOL
S.P.
OPTIONAL
MODULES
VOL
S.P.
HIGH PASS FILTER
STEREO
BRIDGE
HIGH PASS FILTER
OPTIONAL
MODULES
APA2000
