GENERAL
Power output MOSFET 50W
5
4
Power supply 13.2V DC (11—16V)
Dimensions (W
5
H
5
D)
7˝
5
4˝
5
6-1/2˝
(180
5
100
5
165mm)
Weight 5.5lbs (2.5kg)
Dimensions (PND only)
(W
5
H
5
D)
5˝
5
3˝
5
1˝
(130
5
82.5
5
24.5mm)
Weight (PND only) 0.4lbs (0.2kg)
Operating temperature range -4°F to 149°F (-20°C — 65°C)
Operating temperature range
(PND only)
14°F to 131°F (-10°C — 55°C)
DISPLAY
Display 4.3˝ WQVGA
Resolution 391,680 dots (480
5
272
5
3)
FM TUNER
Frequency range 87.75 — 107.9 MHz (200 kHz step)
Usable Sensitivity 15 dBf
AM TUNER
Frequency range 530 — 1,710kHz (10kHz step)
Usable Sensitivity 27dB (1kHz)
CD SECTION
Frequency response 20 — 20,000Hz ±3dB
Wow & Flutter Below measurable limit
S/N Ratio 75 dB
Dynamic Range 95 dB
Total Harmonic Distortion 0.008%
DVD SECTION(Audio Part)
Frequency Response 20 Hz - 20,000 Hz , ± 3dB
Wow & Flutter Below measurable limit
S/N Ratio 70 dB
Dynamic Range 95 dB
Total Harmonic Distortion 0.008%
USB MEMORY PLAYER SECTION
USB Interface 1.1
Frequency Response 20 Hz - 20,000 Hz , ± 3 dB
Channel Separation 65dB
S/N Ratio 75 dB
Total Harmonic Distortion 0.008%
EQUALIZER SECTION
Equalizer
±11db at 80 Hz/±11dB at 700 Hz/
±11dB at 10 kHz
AVN4430 Specifications
Display
Display Size 4.3" WQVGA
Touch Panel Control
●
Dimmer Control
●
Navigation
Navigation Device Flash memory + SD
Built-in Memory Map Storage 2GB
Coverage
US, CA, Hawaii, Alaska, Puerto
Rico
Display Languages 22
Voice Instruction Languages 36
Speed Pulse
●
Gyro Sensor —
POI approx. 2,988,000 points
City Map
●
Emmergency Search
●
(Help me! Menu)
Multiple Routing
●
Real-time Traffic Info
●
(TomTom Traffic)
Last Docked Search
●
Voice Recognition
●
TomTom PLUS Services
●
Map ShareTM
(Real-time Map Update)
●
Easy Map Update (using a PC)
●
Steering Remote-ready
●
Compatible Media/Format
CD, CD-R/RW
●
DVD-Video, DVD-R/RW, DVD+R/
RW
●
DVD Picture Format NTSC
MP3
●
(CD/USB)
WMA
●
(CD)
Audio Functions
Preamp output F/R/NF, 3V 6CH
Video Input
●
Source Volume Control
●
Source Tone Memory
●
Loudness
●
Crossover (Low Pass Filter)
●
EQ
●
(Bass/Mid/Treble)
Balance/Fader control
●
Non-Fader/Phase level control
●
AVN4430 Feature List
CD7200 mkII CD5030 CD1200
CONTROL
Remote Control
● ●
optional
CD Changer Control
● ●
—
CD, CD-R/RW
● ● ●
USB
● ● ●
WMA
● ● ●
MP3
● ● ●
AAC — —
●
SAT Radio-ready
● ●
—
HD Radio-ready
● ●
—
Ready for iPod
®
● ● ●
iTune Tagging (HD Radio) —
●
—
TUNER
AM/FM 6/18 6/18 6/18
Station Name Input
●
— —
AUDIO
Pre Outputs 8V/6ch 5V/6ch 3V/4ch
MOSFET Amplification —
●
—
Advanced 24-bit
Δ∑
DAC
●
— —
Source Volume Control (SVC)
● ●
—
Circle Surround II
●
— —
Parametric EQ
Front 3 way 4 SP+Subwoofer
7 band (4 SP+Subwoofer) —
11 band 7 band
Graphic EQ — —
●
(Easy: 3 band)
Time Alignment
● ●
(Auto/Easy) —
Crossover
● ●
—
Bass/Mid/Treble Control
●
—
●
Loudness
●
(Manual)
●
(Manual)
●
(Manual)
Multi-Harmonizer
● ●
—
Simplified Position Selector —
●
—
Non Fader Level/Phase control
● ●
—
Non Fader Mono/Stereo changeable
● ●
—
Non Fader Pre Outputs
● ●
—
AUX Input
●
(RCA + 1 optional)
●
(RCA + 1 optional)
●
Mute
● ● ●
GENERAL
Display Full Dot VF Monochrome OEL LCD
Illumination 6 pattern Blue/Red Green/Red
Brightness Control —
●
—
Dimmer Control
● ● ●
Bluetooth
®
Wireless Technology
●
(Built-in)
●
(Built-in) —
Hands-free call/Audio Streaming
● ●
—
ESN Security
● ●
—
Detachable Front Panel
● ● ●
Face Type Motorized Flip type Fixed
E-iSERV
Audio Customization
●
— —
Display Customization
● ●
—
14.4V Power Supply CD7200 mkII CD5030 CD1200
Max. Power Output no amplifier section 50W
5
4 (MOSFET) 40W
5
4
Lineout Output Level/Impedance
8V(0dB)/55
Ω
5V(0dB)/55
Ω
3V(0dB)/55
Ω
Tone
Control
Bass/Mid/Treble
±12dB at 80Hz/
±12dB at 630Hz/
±12 at 10kHz
—
±12dB at 100Hz/
±12dB at 680Hz/
±12dB at 10kHz
Loudness
+9dB at 100Hz/+6dB at 10kHz
FM
Frequency Range
USA: 87.75 — 107.9 MHz
(200kHz step)
Latin America:
87.75 — 107.9 MHz
(100kHz step)
USA: 87.75 — 107.9 MHz
(200kHz step)
Latin America:
87.9 — 108.0 MHz (100kHz
step)
USA: 87.75 — 107.9 MHz
(200kHz step)
Latin America:
87.75 — 107.9 MHz
(100kHz step)
Usable Sensitivity
15dBf
Frequency Response
30 — 15,000Hz ±3dB
Stereo Separation
38dB (1kHz)
AM
Frequency Range
USA/Latin America: 530 — 1,710kHz (10kHz step)
Usable Sensitivity
22μV
CD
Frequency Response
20 — 20,000Hz, ±3dB
Wow & Flutter
Below measurable limit
Channel Separation
85dB 80dB
S/N Ratio (A-weighted)
100dB 95dB 90dB
Dynamic Range
98dB 95dB 90dB
Total Harmonic Distortion
0.008%
USB
USB Interface
1.1
Frequency Response
20 — 20,000Hz, ±3dB
S/N Ratio (A-weighted)
100dB 95dB 90dB
Total Harmonic Distortion
0.008%
Weight 1.7kg 1.6kg 1.43kg
Dimensions (W
5
H
5
D) at
maximum
7˝
5
2˝
5
7-5/16˝
(178
5
50
5
185.6mm)
7˝
5
2˝
5
7-1/4˝
(178
5
50
5
184.5mm)
7˝
5
2˝
5
7-7/16˝
(178
5
50
5
188.1mm)
CD Receivers SpecificationsCD Receivers Feature List
Time Alignment
dB level 0dB~-30dB(1dB step)
Delay time 0.05ms step
Control range 0ms~-10ms
Crossover
Control range
for cutoff frequency
High(HPF) : 63Hz~16kHz
Mid (LPF) : 63Hz~16kHz
Mid (HPF) : 20Hz~16kHz
Low (LPF) : 20Hz~16kHz
Slope
PASS/-6/-12/-18/-24 dB/oct
Crossover points 1Hz step
Parametric EQ
Level -10dB~+10dB(0.5dB step)
Bands 11 band(1Hz step)
Q 0.1 step
CD7200 mkII Audio Customize Parameters
(using E-iSERV)
External Interface
Bluetooth Unit Built-in
iPod
●
(iPC-409)
iPod Video
●
(iPC-409)
USB (Audio)
●
HD-Radio —
XM Tuner
●
SIRIUS Tuner
●
AUX input
●
TV Tuner —
Rear View Camera
●
Rear Monitor
●
Other
Illumination Blue/Red
Tilt
●
(6 steps)
TEL Mute —
PND Part Functions
Bluetooth Hands-free Call
●
Mic for Hands-free Call
●
(Built-in)
Opening Picture Customizing
●
Picture Viewer
●
USB Version 1.1, Full-speed
AVN4430 AVN4430
