8
-
ACC ON/OFF power supply terminal (blue/white)
If you use this terminal to connect main unit such as an external amplifier, you can still hear the audio guidance
from the navigation system even when audio is turned off. Connect it to the control terminal for the external
amplifier or other main unit.
※
A popping noise may be heard when the engine is being started or the ignition switch is at the ON position, but
this is normal and is not the sign of a malfunction.
Vehicle speed pulse signal wire (Purple/White)
Connect to the vehicle speed pulse signal terminal.
Parking brake signal wire (Red/White)
Connect to the parking brake signal terminal.
Reverse signal wire (Green)
Connect the reverse signal output of the vehicle to this terminal.
E-LAN terminal (13P)
Connect to the E-LAN terminal of the CD changer, etc.
VTR output terminal (Yellow)
Connect to the monitor with video input.
Back-eye camera external input terminal (4P)
Used with the Eclipse back-eye camera (sold separately).
13
12
11
10
A
B
Main unit connections
D
