Eclipse POWERSHADE - Setting Additional Limit Positions; Setting Mid Limit Positions; Fine Tuning Limit Positions; Fine Tuning Pre-set Limit Positions

SETTING ADDITIONAL LIMIT POSITION(S):
(up to 4 mid limit positions can be set)
1. UsetheUp/Downbuttonsontheremotetomovetheblind
 totherequiredposition
2. PresstheProgram/Learnbuttononthebackoftheremote
until the motor jogs
3. PresstheProgram/Learnbuttononthebackoftheremote
 untilthemotorjogs,limitpositionisnowset
4. Repeatsteps1-3foralldesiredpositions
FINE TUNING PRE-SET LIMIT POSITION(S):
1. Usetheremotetomovetheblindtothepre-setlimitposition
that is to be tuned
2. PresstheProgram/Learnbuttononthebackoftheremote
until the motor jogs
3. UsetheUp/Downbuttonsontheremotetonetunetheposition
4. Withblindinthenewdesiredposition,presstheProgram/Learnbutton
 onthebackoftheremoteuntilthemotorjogs.Newlimitposition
is now set
DELETING AN ADDITIONAL LIMIT POSITION(S):
1. Usetheremotetomovetheblindtothelimitpositionthatistobedeleted
2. PressandholdtheProgram/Learnbuttononthebackoftheremotefor
 approx.7suntilthemotorjogs(pleasenotemotorwilljogaerapprox.
 1-2saerbuttonispressedandthenjogagainaerapprox.7s),limit
 positionisdeleted
DELETING A SINGLE CHANNEL FROM MOTOR MEMORY:
(Please note this will only delete a single pre-programmed channel,
this does not remove any limits)
1. Select the channel on the remote that is to be deleted
2. Press the Set button on the motor until the motor jogs once
3. PresstheProgram/Learnbuttononthebackoftheremote
 untilthemotorjogs,channelisnowdeletedfrommotor
2
PROGRAM BUTTON
LEARN BUTTON
Eclipse Blinds Systems Inchinnan Business Park Renfrew Scotland PA4 9RE
Customer Support: +44 (0)141 814 3500
