Eclipse Solar RGB-700 - Trouble Shooting

DMX Channel
CH1
Mode
0
-
63
Laser OFF
64
-
127
Auto Mode
128
-
191
Sound Active
192
-
255
DMX Mode (CH2~CH8 valid)
CH2
Pattern Select
0
-
255
Selecting built
-
in patterns
CH3
Zooming
0
-
127
Manual adjust the pattern size
128
-
255
Loop Zooming In or O
ut
CH4
X Axis rolling
0
-
127
Manual rolling
128
-
255
Choose the rolling speed
C
H5
Y Axis rolling
0
-
127
Manual rolling
128
-
255
Choose the rolling speed
C
H6
Z Axis rolling
0
-
127
Manual rolling
128
-
255
Choose the rolling speed
CH7
X Axis Moving
0
-
127
Manual adjust
position
128
-
255
Choose the horizontal moving speed
CH8
Y Axis Moving
0
-
127
Manual adjust the position
128
-
255
Choose the vertical moving speed
CH9
Colours
0
-
63
Original
64
-
95
Red
96
-
127
Green
128
-
159
Blue
160
-
191
Yellow
192
-
223
Pink
224
-
255
Cyan
Trouble Shooting:
1. If the power indicator is off and the laser doesn't work, please check the power supply and input connection
2. In Sound mode if the power supply indicator is ON and the sound active indicator is OFF but the laser doesn't work;
a. Check sound sensitivity level
b. Check run mode is set to Sound Mode and not DMX or Slave Mode.
3. In Master/Slave mode the slave lasers aren't working;
a. Check that there's only 1 master in the chain
b. Make sure your connections and cables are secure
c. Check the master is on an auto mode (sound / auto)
4. In DMX mode, the unit can't be controlled with a DMX controller but the DMX signal is flashing.
a. Check the DMX address is the same on the controller and the unit
b. Check the DMX controller is not on 'blackout'
5. If the output beam direction is skewed or of centre, reset the unit. If problem persists return to place of purchase for
calibration.
6. If the unit fails, power OFF and wait 5 minutes before powering on again.
If you come across additional problems contact the manufacturer AVE on 03 9706 5325
