- 4 -
General Installation Guide
Installation Environment
The battery should be installed in a clean, cool, and dry place, keeping water, oil, and
dirt away from the battery. The accumulation of these materials on the battery can
cause current leakage, resulting in self-discharge and a possible short-circuit.
Sufficient air flow must be provided to prevent excessive heat build-up and to
minimize temperature variation between the batteries.
Preparation
Before the installation and operation of the battery, it is recommended to have the
following equipment or tools available:
Proper Protective Equipment Insulated Tool(s)
Multimeter Battery Cable
Battery Charger / Charge Controller
1.4.1.3
0 2000 3000 4000 5000 6000 7000 8000 9000
100
90
80
70
60
50
40
SLA Battery Cycles LiFePo4 Battery Cycles
Capacity (%)
30%DOD
50%DOD
80%DOD
100%DOD
Cycle Life & Capacity @ LiFePO4 Battery Cycles
