BS PLUG WIRING
Wiring Instrucons: Should it be necessary to change the plug, please note the wires in the mains lead
are coloured in accordance with the following codes:
BLUE - NEUTRAL
BROWN – LIVE
GREEN AND YELLOW - EARTH
In the event that the colours of the wires in the mains lead of this appliance do not correspond with the
coloured markings idenfying the terminals in your plug, proceed as follows:
1. The BLUE wire is NEUTRAL and must be connected to the terminal which is marked with the leer N or
coloured BLACK.
2. The BROWN wire is LIVE and must be connected to the terminal which is marked with the leer L or col-
oured RED.
3. The GREEN/YELLOW is EARTH and must be connected to the terminal which is marked with the leer E
or or coloured GREEN or GREEN/YELLOW.
4. Always ensure that the cord grip is posioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be ed with a 13A fuse. If in doubt consult a
qualied electrician.
Wiring for a 13 Amp Plug (BS1363)
Please note. The Earth Terminal is marked with the leer E or Earth Symbol.
BS PLUG WIRING
Earth - (Green/Yellow)
Neutral - N (Blue) Live - L (Brown)
