You should see 4 types of wires in your
wall box. Here’s how to identify them.
Identify
wires
4
Line and load wires (black or red)
are connected to your existing switch.
Ground wire (exposed copper or green)
typically comes from the wall box.
Neutral wires (white)
typically come in a pair and are
fastened together by a wire nut.
Needed for installation.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ecobee Switch+ and is the answer not in the manual?

Ecobee Switch+ Specifications

General IconGeneral
TypeSmart Light Switch
ConnectivityWi-Fi
Voltage120V
Amperage15A
Wattage1800W
Load Capacity600W incandescent, 150W LED/CFL
ColorWhite
Voice ControlAmazon Alexa
CompatibilityAmazon Alexa, Google Assistant
SensorsOccupancy
Wireless ProtocolWi-Fi 802.11 b/g/n
