Ecoflam Max Gas 70 P AB User Manual

420010386101 Max Gas 70-105-120 P AB420010386102 Max Gas 70-105-120 P AB
pag.2
MODELS A B C D D1 E F G I L M N O P
MAX GAS 70 P AB 386 155 231 85 185 282 89 160 100/120 100/120 M8 52 71 82
MAX GAS 105 P AB 400 169 231 140 220 282 89 160 100/120 100/120 M8 52 71 82
MAX GAS 120 P AB 400 169 231 160 240 282 98 160 100/120 100/120 M8 52 71 82
D = SHORT HEAD D1= LONG HEAD
WORKING FIELDS
Max Gas 70 P AB Max Gas 105 P AB Max Gas 120 P AB
Termal power max. kW 70 108 120
kcal/h 60.340 96.100 103.450
Termal power max kW 25 40 40
kcal/h 21.600 34.480 34.480
TECHNICAL DATA
OPERATING FEATURES
Models : Max Gas 70-105-120 PAB Gas family
G20 G25 G31 G30
Max. gas pressure* mbar 360 360 360 360
Min. gas pressure* mbar 12 12 30 30
Fuel L.C.V. kcal/Nm
3
8.570 7.370 22.260 29.320
Models : Max Gas 70 PAB
Gas flow rate max. 7,04 Nm
3
/h 8,19 Nm
3
/h 2,71 Nm
3
/h 2,06 Nm
3
/h
min. 2,52 Nm
3
/h 2,93 Nm
3
/h 0,97 Nm
3
/h 0,74 Nm
3
/h
Models : Max Gas 105 PAB
Gas flow rate max. 11,21 Nm
3
/h 13,04 Nm
3
/h 4,32 Nm
3
/h 3,28 Nm
3
/h
min. 4,67 Nm
3
/h 4,68 Nm
3
/h 1,55 Nm
3
/h 1,17 Nm
3
/h
Models : Max Gas 120 PAB
Gas flow rate max. 12,07 Nm
3
/h 14,04 Nm
3
/h 4,65 Nm
3
/h 3,53 Nm
3
/h
min. 4,67 Nm
3
/h 4,68 Nm
3
/h 1,55 Nm
3
/h 1,17 Nm
3
/h
Output
Backpressure in comb. chamber
CB
A
E
D-D1
F
G
M
126
151
I
L
NP
O
178,5
5
2
,5
OVERALL DIMENSIONS
* : Minimum/maximum gas inlet pressures depend by the gas train matched to the burner. The values are written on the gas trains manual.
10 20 30 40 50 60 70
0
0,5
1
1,5
2
2,5
3
3,5
4
10 20 30 40 50 60 70 80
kcal/h
x 1000
kW
80
90
100
90 100 110 120
MAX GAS 105 PAB
mbar
MAX GAS 120 PAB
MAX GAS 70 PAB
MAX GAS 70 PAB
Gas family : AT I
2H,
I
3B/P
BE I
2E(R)B,
I
3P
DE I
2E,
I
3B/P
DK I
2H,
I
3B/P
SE I
2H,
I
3B/P
ES I
2H,
I
3P
FI I
2H,
I
3B/P
FR I
2Er,
I
3B/P
GB I
2H,
I
3B/P
NL I
2L,
I
3B/P
GR I
2H,
I
3B/P
IE I
2H,
I
3B/P
IT I
2H,
I
3B/P
PT I
2H,
I
3B/P

Ecoflam Max Gas 70 P AB Specifications

General

Brand	Ecoflam
Model	Max Gas 70 P AB
Category	Indoor Fireplace
Language	English
