Ecoflo Coco Filter EC7 Series - Pump Performance Curve and Identification

Premier Tech Aqua 29/32 Polyethylene Ecoflo
®
Coco Filter– Installation Guide CAN/USA
339975 Rev. 5.0
6.11 Pump performance curve
The figure below illustrates the performance
curve of the pump built into the polyethylene
Ecoflo
®
Coco Filter. Note that this curve was
produced in clean water and that the pump’s
performance may not be as high in
wastewater. If you have questions on how to
interpret this curve, please contact the
customer service department of Premier
Tech Aqua.
Pump characteristics:
• 0.5 HP
• 8.5 A
• Single phase, 60 Hz, 115 V
6.12 Identification and warranty seals
On the sticker provided, check the Ecoflo
®
Coco Filter model installed and the type of discharge. Refer to the
example on the Ecoflo
®
Coco Filter 3.4 sticker. (- P for Pumped - G for Gravity)
Next, install the insulating panel and seal it in place using the two Premier Tech fasteners.
Once in place, these fasteners hold the collar of the Ecoflo
®
Coco Filter to the handle of
the insulating panel. Finally, use the lag screws to close the main cover. Note that the
owner has nothing in particular to do to begin using the system.
Don’t forget the inspection permit, where applicable.
