EcoFlow Alternator - Page 18

Specifications
Model
EF-FC-301-1
Net Weight
Approximately 2.3 kg
Dimensions
(W × D × H)
242×194×35 mm
(9.5×7.6×1.4 inch)
Wi-Fi
Frequency: 2412MHz-2472MHz - Maximum output power: 18.22dBm
Bluetooth
Frequency: 2402MHz-2480MHz - Maximum output power: 7.89dBm
Charge Mode
Input: 12V/24V⎓(11V-31V⎓), 76A Max.
Output: 40V-60V⎓, 800W Max.
Battery Maintenance
Mode
Input: 40V-60V⎓, 3A Max. | Output: 13.8V/27.6V⎓, 100W Max.
Reverse Charge Mode
Input: 40V-60V⎓, 21A Max. | Output: 13.8V/27.6V⎓, 800W Max.
Rated Current of Fuse
125A
Protection Type
Reverse polarity protection/Overcurrent protection/Short circuit protection/Overvoltage and
undervoltage integral protection against overloads)
Operating Temperature
–20℃ to 60℃(–4℉ to 140℉)
Storage Temperature
–30℃ to 70℃(–22℉ to 158℉)
Operating Humidity
Storage Humidity
≤95%
≤95%
