EcoFlow DELTA Max User Manual

4
3.2 LCD Screen
3.3 General Product Usage
Short Press to Turn On Long Press to Turn Off
Remaining Charge/
Discharge Time
Overload Warning
Fan Indicator
Low Temperature Warning
High Temperature Warning
Remaining Battery Percentage
Battery Failure Warning
Battery Level Indicator
Extra Battery Indicator
AC Output
Wi-Fi Status
12V DC Output Indicator
State of Charge
USB-A Output
USB-C Output
Output Power
Input Power
Battery Level Indicator: The indicator will repeatedly fill while charging. If product is at 0% charge, the
indicator will flash to warn you.
Wi-Fi Status: After pressing the IOT button for 3 seconds, the Wi-Fi status will flash on the LCD screen
which indicates that the product is ready for pairing. There're two ways to connect the product with
the App, either directly connect to the product's hotspot or using the Internet. If the App is successfully
connected to the product's hotspot, the icon will keep flashing; if it is successfully connected to the
Internet, the icon will stay on.
* See Section 5 for more troubleshooting steps.
Short press the Main Power Button to turn on the product; the LCD Screen will light up and the
battery level indicator icon will display.
Product On, Product Off, LCD Screen On
The product enters sleep mode after 5 minutes of idle operation; the LCD Screen will automatically
turn off. When the product senses any load change or operations, the LCD Screen will automatically
light up. To turn the LCD Screen on or off, please short press the Main Power Button.
To power off the product, press and hold the Main Power Button.
The default product standby time is 2 hours. With other Power Buttons turned off and no other load
access for 2 hours, the product will automatically shut down. The standby time can be set on the App.

EcoFlow DELTA Max Specifications

General

AC outlets quantity	6 AC outlet(s)
Built-in air compressor	-
Input current	13, 12/24 A
Output voltage	5, 9, 12, 15, 20, 12.6 V
AC input voltage	11-100, 12/24 V
Maximum input power	1600 W
USB Type-A output ports	4
USB Type-C ports quantity	2
Wi-Fi	Yes
Charging source	AC, Cigar lighter, Solar, USB
Battery capacity	1612 Wh
Solar panel power	800 W
Total output power	2500 W
Solar panel current	13000 mA
Solar panel voltage	11-100 V
Number of charging cycles	800
Product color	Black
Housing material	Aluminium, Plastic
Cables included	AC, Cigar lighter
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	242 mm
Width	497 mm
Height	305 mm
Weight	21500 g
Package depth	355 mm
Package width	636 mm
Package height	430 mm
Package weight	24300 g
