|13
En
5 CAN3H
Inverter cascading communication H
(Reserved)
6 SG_Ready21
7 CAN3L
Inverter cascading communication L
(Reserved)
Inverter cascading communication H
Inverter cascading communication L
Meter communication
Meter communication
Inverter cascading sync signal grounding
Sync signal
Emergency Stop Input
Emergency Stop Input
8 SG_Ready22
9 CANH 10 AGND1
11 CANL 12 SYN
485A1 14 EPO1_dry1
485B1 16 AGND1
1 CAN0H
3 CAN0L
2 SG_Ready11
4 SG_Ready12
• COM terminal supports logic interface connection. Logic interface is required by some local
regulations that can be operated by a simple switch or contactor.
• When the switch is closed, the inverter can operate normally.When the switch is opened, the
inverter will reduce its active power to zero within 5s.
• Pin14 and Pin16 of COM terminal is used for the logic interface conneaction.
1
2
×2
A6
A6
43
5
7 8
Connecting
Communication Connector
1
2
3
4
5
6
7
8
To Next Page
