Expansion Power Port
PRO EXPANSION KIT
Expansion Power Port
STU
Features of PRO KIT
1. Expansion Power Port
2 & 3. 24V-/24V+ M6 Port
This set of terminals is used for connecting the external 24V lead-acid battery or 24V lithium iron
phosphate battery to expand the capacity of R600 PRO. Please make sure the positive and negative
terminals are connected with the external battery correctly, otherwise the PRO KIT might be damaged.
This port is used for connecting the R600 PRO and PRO KIT with the expansion power cable. The firmware
of PRO KIT can be upgraded when connected to R600 PRO . When connecting with the external battery, the
maximum current and output are 8A (charging) and 750W (discharging) respectively.
