5.9. External auxiliary equipment
This is used to control the activation of the auxiliary equipment integrated in the DHW heating buffer storage tanks via outputs to
relays. They are also used to control activation of the all / nothing external auxiliary boiler. If modulating boilers are installed, it is
also used to control the temperature downstream from the boiler, so the heat pump and the boiler can function simultaneously.
The connection terminals of the SG3 outlet unit are used to manage the auxiliary boilers, so this one cannot be used.
Description
Signal
Type
Connector
Auxiliary heating buffer storage tank equipment
Digital output
Activation 230Vac / 1A maximum
DO10
DHW inter-storage tank auxiliary equipment
Digital output
Activation 230Vac / 2A maximum
DO11
Auxiliary boiler
Analogue input
NTC 10K 25ºC Probe
AI13
Analogue output
Fan regulation 0 – 10Vdc
AO4
Digital output
Activation 230Vac / 2A maximum
DO14
Table 1.5. Auxiliary equipment connection terminals.
5.10. Aerothermal or hybrid brine systems
These are used to control activation of the aerothermal (ecoGEO AU12) and geothermal brine systems. They also generate a
regulation signal for the variable speed fan of the ecoGEO AU12 unit.
The connection terminals of the SG2 outlet unit are used to manage the aerothermal brine units, so this one cannot be used.
Description
Signal
Type
Connector
Aerothermal collector (ecoGEO AU12)
Analogue input
NTC 10K 25ºC Probe
AI12
Analogue output
Regulation 0 – 10Vdc
AO3
Relay digital output
Defrost activation
230Vac / 2A maximum
DO6
Relay digital output
Fan activation
230Vac / 2A maximum
DO16
Geothermal collector
Relay digital output
Activation 230Vac / 2A
maximum
DO17
Table 1.6. Connection terminals for aerothermal or hybrid brine systems.
5.11. Alarm signal
If the heat pump cannot start up the compressor because of an active alarm, the heat pump will generate an alarm signal.
Description
Signal
Type
Connector
Alarm signal
Relay digital output
Activation 230Vac / 2A
maximum
DO9
Table 1.7. Connection terminals for aerothermal or hybrid brine systems.
