4
Use
>< Keys to set
Start Stop
Oxy 8:00A- 4:00P-
Press NEXT when done
OXY FUNCTION
The next step is to setup the "OXY" mode. Typically residential pools
should run 6 to 10 hours per day, commercial pools 18 to 24 hours per day.
This is how long you are going to want to set up the "OXY" mode. It is strongly
recommended that the running time of the Oxygen should be done during day-
light hours. The parameters for the "OXY" mode must also be set within the
"POOL" parameters. Now press the "OXY" key and the screen will display as
shown:
The cursor automatically starts on the hour hand of the Start time. Use
the "UP" and "DOWN" arrow keys to set the hour hand. Then press the
"RIGHT" arrow key to move to the minute hand. Repeat the same process
until the Start time (Hours/Minutes) and the Stop time (Hours/Minutes) are set
to run "OXY" for the appropriate length of time, and within the pool pump
parameters. Press "NEXT WEEK" when all values are correct.
The screen should now display the correct TIME, DATE, POOL "On"
and "Off," and OXY "On" and "Off." The "Home Screen" will look as follows:
NEXT WEEK FUNCTION
The next step is to setup your ION mode. The NEXT WEEK feature
allows you to set a DAY and a TIME period for Copper Ionization to occur.
The ionization will occur once per week on the day and the time selected with
this feature. It is NOT recommended that future ION settings be programmed
without an operating history. Actual Ion time needed is often less than one full
Oxy cycle.
SPECIAL NOTE: If you select MANual or ION which will turn
ION on for the POOL run time, or OXY run time, the setting for NEXT
WEEK will need to be reset. In addition, no OXY or ION will actually
occur outside the time parameters entered for POOL.
WARNING: Never set OXY or ION to start and stop during times
when your pool pump is not running.
8:51:04A 1/11/2005
Pool 8:00A- 4:00P+
Oxy 8:00A- 4:00P+
Ion None
^
^
13
- ASK ABOUT PHOSPHATE FILTERS -
