Ecox EIHPTC Series - Page 3

3
EIHPTC
CEILING FLOOR TYPE
1
1
4
2
2
5
3
3
6
INDOOR UNIT
OUTDOOR UNIT
NOTE
All the pictures in this manual are for explanation purpose
only. They may be slightly dierent from the air conditioner you
purchased (depend on model). The actual shape shall prevail.
Air ow louver (at air outlet)
Air inlet (with air lter in it)
Installation part
Display panel
Remote control
Drain pipe
Connecting pipe
Air inlet
Air outlet
FIG. 1-1
OR
1
2
3
5
4
7
6
8
8
8
8
8
8
9
9
7
