Using BIOS
Shutdown Temperature (Disabled)
Enables you to set the maximum temperature the system can reach before powering down.
System Component Characteristics
These fields provide you with information about the systems current operating status. You
cannot make changes to these fields.
PCI/VGA Palette Snoop (Disabled)
This item is designed to overcome problems that can be caused by some non-standard VGA
cards. This board includes a built-in VGA system that does not require palette snooping so
you must leave this item disabled.
Assign IRQ For USB (Enabled)
Names the interrupt request (IRQ) line assigned to the USB on your system. Activity of the
selected IRQ always awakens the system.
INT Pin 1-8 Assignment (Auto)
Identifies the interrupt request (IRQ) line assigned to a device connected to the PCI inter-
face of your system.
• CPU Core Voltage
• DDR Voltage
• 3.3V
• 5.0
• +12V
• Voltage Battery
• CPU Temperature
• System Temperature
• CPU FAN Speed
• SYS FAN Speed
• PWR FAN Speed
PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature [Disabled]
CPU Core Voltage
DDR Voltage
Vcc 3.3V
Vcc 5.0V
+12V
Voltage Battery
CPU Temperature
System Temperature
CPU FAN Speed
SYS FAN Speed
PWR FAN Speed
Item Help
Menu Level
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
To Next Page
