Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
1 CPU Socket LGA775 socket for Pentium 4 CPUs
2 CPUFAN1 CPU cooling fan connector
7 SATA1~4 Serial ATA connectors
5 ATX1 Standard 24-pin ATX power connector
8 PANEL1 Panel connector for case switches and LEDs
4 FDD1 Floppy diskette drive connector
LABEL COMPONENT
6 IDE1 Primary IDE channel
3 DIMM1/3 184-pin DDR SDRAM slots
9 SPK1 Speaker header
10 CASFAN1 Case cooling fan connector
21 PWR1 Auxiliary 4-pin power connector
19 PCI-E2 PCI Express x1 slot
12 USB3-4 Front Panel USB headers
11 CLR_CMOS1 Clear CMOS jumper
16 PCI1~3 32-bit add-on card slots
17 CDIN1 CD-in header
14 AUDIO1 Front panel audio header
15 SPDIFO1 SPDIF out header
18 PCI-E1/E3 PCI Express x16 slots
20 PWRFAN1 Power cooling fan connector
13 ATX4P1 Auxiliary power connector for graphics interface
