ECS 915PL-A2 - ATX 12 V Power Connector; ATX 24-Pin Power Connector

11
Installing the Motherboard
CPUFAN1: CPU Cooling FAN Power Connector
CASFAN1/PWRFAN1: System Cooling FAN Power Connectors
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
1 GND System Ground
2
+12V Power +12V
3 Sense Sensor
4 PWM CPU FAN control
Users please note that the fan connector supports the CPU cooling
fan of 1.1A~2.2A (26.4W max.) at +12V.
Pin Signal Name Function
Pin Signal Name Function
PWR1: ATX 12V Power Connector
4 +12V
3 +12V
2 Ground
1 Ground
SPK1: Internal speaker
4 Signal
3 Ground
2 Key
1 VCC
Pin Signal Name
ATX1: ATX 24-pin Power Connector
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 COM
4 +5V 16 PS_ON
5 Ground 17 COM
6 +5V 18 COM
7 Ground 19 COM
8 PWRGD 20 -5V
9 +5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 COM
Pin Signal Name Pin Signal Name
Pin Signal Name
