ECS A785GM-M5 User Manual

40
Using BIOS
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the fan
speed will be auto minimized for quiet environment. If you choose Silent mode, the
fan speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
Smart Fan Mode Quiet
SMART Fan start PWM value 20
SMART Fan start TEMP.(°C) 52
DeltaT1 +3
SMART Fan Slope PWM value 8 PWM value/°C
CPU FAN Full Limit Temp 65°C
Normal: auto ajusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the Smart Fan Function page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
Smart Fan Mode Quiet
SMART Fan start PWM value 20
SMART Fan start TEMP.(°C) 52
DeltaT1 +3
SMART Fan Slope PWM value 8 PWM value/°C
CPU FAN Full Limit Temp 65°C
Normal: auto ajusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the Smart Fan Function page.

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10

Weight and Dimensions

Depth	210 mm
Width	244 mm
