ECS A785GM-M5

41
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
Smart Fan Mode Silent
SMART Fan start PWM value 5
SMART Fan start TEMP.(°C) 60
DeltaT1 +3
SMART Fan Slope PWM value 14 PWM value/°C
CPU FAN Full Limit Temp 68 °C
Normal: auto ajusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the Smart Fan Function page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
Smart Fan Mode Manual
SMART Fan start PWM value 28
SMART Fan start TEMP.(°C) 27
DeltaT1 +3
SMART Fan Slope PWM value 3 PWM value/°C
CPU FAN Full Limit Temp 60 °C
Normal: auto ajusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the Smart Fan Function page.
SMART Fan start PWM value (28)
SMART Fan start TEMP. (°C) (27)
This item is used to set the start PWM value of the smart fan.
This item is used to set the start temperature of the smart fan.
DeltaT1 (+3)
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
