Using BIOS

Press <Esc> to return to the PC Health Status page.

SMART Fan Slope PWM value (8 PWM value/°C)

This item is used to set the Slope Select PWM of the smart fan.

System Component Characteristics

These items display the monitoring of the overall inboard hardware health events,

such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan

speed,...etc.

• CPU Temperature

• NB Temperature

• CPU Fan Speed

• CPU Vcore

• VDIMM

Press <Esc> to return to the main menu setting page.

Shutdown Temperature (CPU)

Enable you to set the maximum temperature the CPU can reach before powering

down

This item is used to set the limit temperature of the smart fan.

CPU FAN Full Limit Temp (65°C)

Shutdown Temperature (NB)

Enable you to set the maximum temperature the NB can reach before powering down

Case Open Warning (Disabled)

This item enables or disables the warning if the case is opened up, and the itembelow

indicates the current status of the case.

Chassis Opened (No)

This item indicates whether the case has been opened.

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-M5 and is the answer not in the manual?

ECS A785GM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
Power fan connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Motherboard chipset	AMD 785G
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Graphics card	Radeon HD 4200
Maximum graphics card memory	512 MB
RAID levels	0, 1, 10
