6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket Socket for AMD Phenom
TM
II (socket AM3) processor
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE connector
6. SATA1~6 Serial ATA connectors
7. F_PANEL Front panel switch/LED header
8. SPK Speaker header
9. SYS_FAN System cooling fan connector
10. CLR_CMOS Clear CMOS jumper
11. F_USB1~3 Front panel USB headers
12. SPDIFO SPDIF out header
13. CD_IN Analog audio input connector
14. F_AUDIO Front Panel Audio header
15. PCI1~2 32-bit add-on card slots
16. CASEOPEN Chassis detect header
17. PCIE1 PCI Express x1 slot
18. PCIEX16 PCI Express x16 graphics card slot
19. ATX12V 4-pin +12V power connector
