4
Introducing the Motherboard
• AMD 785G & AMD SB710
• Socket for Phenom
TM
II (socket AM3) processor
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 1333 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1333/1066 DDR3 SDRAM
• 1 x PCI Express x16 slot
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by AMD SB710 Express Chipset
• 6 x Serial ATA 3.0 Gb/s Host Controllers
• Supports RAID 0, 1, and 10
• 2 x Ultra DMA133/100/66 devices
• VIA VT1705 6-ch High Definition audio CODEC
• Atheros AR8131M Giga LAN Fast Ethernet Controller &
AR8132M 10/100 LAN Fast Ethernet Controller (optional)
• 1 x PS/2 keyboard & PS/2 mouse connector
• 6 x USB ports
• 1 x DVI port
• 1 x VGA port
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in and line out)
• 24-pin ATX Power Supply connector, 4-pin 12V connector
• 1 x CPU_FAN
• 1 x SYS_FAN
• 6 x SATA 3Gb/s connectors
• 3 x USB 2.0 headers support additional 6 USB ports
• 1 x Front panel header
• 1 x Chassis Intrusion Detect header
• 1 x SPDIF out header
• 1 x Front panel audio header
• 1 x Speaker header
• 1 x CD in header
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 8Mb SPI ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supports ACPI revision 3.0 specification
System BIOS
Form Factor • Micro ATX Size, 244mm x 210mm
CPU
Specifications
To Next Page
