H110M4-C23/C2H/C21 USER MANUAL
1
Brief Introduction
Specifications
CPU
•Intel
®
H110 Chipset
Chipset
• Supported by Intel
®
H110 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Storage
• LGA1151 socket for Intel
®
Skylake processor
• Supports CPU up to 65W
Note: Please go to ECS website for the latest CPU support list.
• 1 x PS/2 mouse & PS/2 keyboard connector
• 2 x HDMI ports (or 1 x HDMI port or 0 x HDMI port)*
• 1 x D-sub port (VGA port)
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio 6-ch jacks (line-in, line-out, microphone)
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit Lan
• Realtek ALC662-VD0-GR 6-CH High Definition audio CODEC
- Compliant with HD audio specification
Audio
Expansion
Slots
• 1 x PCI Express x16 Gen3 slot
• 1 x PCI Express x1 Gen2 slot
• Dual-channel DDR4 memory architecture
• 2 x 288-pin DDR4 LONG DIMM sockets support up to 32 GB
• Supports DDR4 2400 MHz DDR4 SDRAM
Memory
Note: Please go to ECS website for the latest Memory support list.
Note: *H110M4-C23 has two HDMI ports, H110M4-C2H has one HDMI
port, and H110M4-C21 has no HDMI port.
Internal I/O
Connectors &
Headers
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x SATA 6Gb/s connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x COM header
• 1 x Clear CMOS jumper
• 1 x Buzzer header
• 1 x Case open header
