DRAM Memory Mapping
Scroll to this item and press <Enter> to view the following screen:
Chipselect Interleaving (Auto)
Use this item to interleave memory blocks across teh DRAM chip slects for mode 0.
BankGroupSwap (Auto)
Use this item to select the BankGroupSwap: Disable/Enabled/Auto.
Address Hash Bank (Auto)
Use this item to select the Address Hash Bank: Disable/Enabled/Auto. Enable or
disable bank address hashing.
Address Hash CS (Auto)
Use this item to select the Address Hash CS: Disable/Enabled/Auto. Enable or
disable CS address hashing.
Press <Esc> to return to the UMC Common Options page.
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Interleave memory blocks
across the DRAM chip
selects for mode 0.
DRAM Memory Mapping
Chipselect Interleaving Auto
BankGroupSwap Auto
Address Hash Bank Auto
Address Hash CS Auto
Press <Esc> to return to the DDR4 Common Options page.
Press <Esc> to return to the UMC Common Options page.
