Chapter 1
2
H81H3-M5 USER MANUAL
CPU
Specifications
• Intel
®
H81 Express Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 slot
• Supported by Intel
®
H81 Express Chipset
- 2 x Serial ATA 3Gb/s devices
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse combo connector
• 1 x D-Sub port (VGA)
• 1 x DVI port (colay HDMI port)
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 3.0 ports (blue)
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
LAN • Realtek 8111G Gigabit LAN (co-lay 10/100 LAN)
• LGA1150 socket for Intel
®
Haswell Processor
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x SATA 3Gb/s connectors
• 2 x SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x CLR_CMOS header
• 1 x Speaker header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Parallel port header(LPT)
• 1 x LDC header
• 1 x SPDIF out header
• 1 x ME_UNLOCK header
Internal I/O
Connectors &
Headers
• Realtek ALC662
-
6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
To Next Page
